Technical Specification

Design Standard: API, ASME, EN, ISO, JIS, DIN, BS, GB

Connection type: Flange, SW, NPT, BW, Wafer, Lug type

Pressure range: 150LB~1500LB, 1.0MPa~25.0MPa, JIS10K~100K

Size range: NPS1/2”-42”, DN15~DN1200

Design Feature:

Lift type / Swing type/ Dual plate

Full bore / Reduce bore

Bolted bonnet

Renewable seat / integral seat

Plug type disc/Flat type disc

Main Part Material :

CF8、CF3、CF8M、CF3M、CG8M、CG3M、CF8C、CK20

304、304、316、316L、316Ti、317、317L、310、310S

F304、F304、F316、F316L、F316Ti、 F317、F317L、F310、F310S
