Technical Specification

Design Standard: API, ASME, EN, ISO, JIS, DIN, BS, GB

Connection type: Flange, SW, NPT, BW

Pressure range: 150LB~1500LB, 1.0MPa~25.0MPa, JIS10K~100K

Size range: NPS3/8”-16”, DN10~DN400

Drive: Hand wheel, Gear, Electric, Pneumatic actuator

Design Feature:

Full bore / Reduce bore

Bolted bonnet

Renewable seat / integral seat

Conical type disc/Flat type disc

Main Part Material :

Hastelloy B、Hastelloy B-2、Hastelloy C276、Hastelloy C-22、Hastelloy C-4、Hastelloy G、Hastelloy G30

N12MV、N7M、CW12MV、CX2MW、CW2M

N10001、N10665、N10276、N06022、N06455、N06007、N06030
