Technical Specification

Design Standard: API, ASME, EN, ISO, JIS, DIN, BS, GB

Connection type: Flange, SW, NPT, BW

Pressure range: 150LB~600LB, 1.0MPa~11.0MPa, JIS10K~40K

Size range: NPS1/2”-16”, DN15~DN400

Drive: Lever, Gear, Electric, Pneumatic actuator

Design Feature:

Full bore or Reduce bore

Fixed structure

Double gland structure

Fire safe design, Anti-static device

Packing box design

Anti-erosion adjustable structure

The surface form a protective film after Hard face treatment on trim. It not only improves anti-corrosion performance, but also can open and close easily because of improved surface hardness.

Main Part Material :

Zirconium 702、Zirconium 705

702C、705C

R60702、R60705
