Technical Specification

Design Standard: API, ASME, EN, ISO, JIS, DIN, BS, GB

Connection type: Flange, Wafer, Lug

Pressure range: 150LB~300LB, 1.0MPa～4.0MPa、 JIS10K～20K

Size range: NPS3”-48”, DN50~DN1200

Drive: Lever, Gear, Electric, Pneumatic actuator

Design Feature:

Double eccentric / Triple eccentric

Resilient seat/Metal to metal seat

Zero leakage

Blow-out proof stem

Fire safe, Anti-static design

ISO 5211 mounting pad

The surface form a protective film after Hard face treatment for trim. It not only improves anti-corrosion performance, but also can open and close easily because of improved surface hardness.

Main Part Material :

Titanium Gr2、Gr3、Gr5、Gr6、Gr7、Gr12

Titanium GrC2、GrC3、GrC5、GrC6、Ti-Pd7B、GrC12

Titanium GrF2、GrF3、GrF5、GrF6、GrF7、GrF12
