Technical Specification

Design Standard: API, ASME, EN, ISO, JIS, DIN, BS, GB

Connection type: Flange, SW, NPT, BW

Pressure range: 150LB~1500LB, 1.0MPa~25.0MPa, JIS10K~100K

Size range: NPS3/8”-42”, DN10~DN800

Drive: Hand wheel, Gear, Electric, Pneumatic actuator

Design Feature:

Solid wedge / Flexible graphite

Full bore / Reduce bore

Bolted bonnet

Renewable seat / integral seat

Hard face treatment for trim surface, then the surface form a protective film. It not only improves anti-corrosion performance, but also can open and close easily because of improved surface hardness.

Main Part Material :

Titanium Gr2, Titanium Gr3, Titanium G5, Titanium Gr6, Titanium Gr7, Titanium Gr12

Titanium GrC2、GrC3、GrC5、GrC6、Ti-Pd7B、GrC12

Titanium GrF2、GrF3、GrF5、GrF6、GrF7、GrF12
